Nullifire FF197 Gun Grade Fire Rated PU Foam

Professional use only – from the 24th August 2023, adequate training is required before industrial or professional use of this product.
Should you require training, visit – https://www.safeusediisocyanates.eu/
Nullifire FF197 Gun Grade Fire Rated PU Foam is a modified, single component, fire rated polyurethane foam, used to seal linear gaps throughout the fire rated areas of a building.
Please see the Product Data Sheet for detailed application and safety information before use.

Quick Links – Click To Jump To Section:


Features & Benefits
Application Notes
Limitations

Features & Benefits


A modified, single component, fire rated polyurethane foam used to seal door frames and linear gaps throughout the fire rated areas of a building
This pink fire foam is easy to identify and cures to form a semi-rigid foam that can accommodate some degree of movement of the joint
Acts as an effective fire seal for up to 4 hours (BS EN 1366-4) when used with Nullifire FS702 Intumescent Acrylic or Nullifire FS703 Silicone Sealant
Also tested to BS EN 1634-1 and meets BS 476-20 & 22
Approved for use within: Single Door, door and a quarter, door and a half and double doors
Works with standard plastic and standard wooden packers
No architrave required (but can be added if required)
Suitable for gaps up to 35mm
Up to 4 hours on linear gaps
Also gives 30 minutes on all the above doors at a reduced frame width of 70mm
Tack free time in just 10 minutes
Gun and straw compatible

Application Notes

Preparation

Ensure suitability of the product prior to use
Protect all surrounding areas and substrates which are required to remain free of FF197
Surfaces must be solid and stable
Remove all loose particles, dust and grease
A speedier cure can be attained by moistening the substrates if needed

Application

Immediately prior to use shake canister vigorously at least 20 times
Remove the protective cap and screw onto the Nullifire PU foam gun or use the nozzle provided
Fill approximately 80% of the required depth of the cavity because the foam will expand
Work upwards on all vertical surfaces
The foam is set in approximately 1 hour (depending on temperature and humidity); excess can be trimmed with a suitable cutting knife
Applying a light misting of clean water between each layer before subsequent application will permit faster cure and increase density

Please see the Product Data Sheet for detailed application and safety information before use.

Limitations

As with all PU foams, FF197 will not adhere to Teflon, polyethylene or silicone coated surfaces
The cured foam is adversely affected by UV light and should be covered with a suitable sealant such as FS703 silicone or FS701 intumescent acrylic.

Please see the Product Data Sheet for detailed application and safety information before use.
